Flexible FPC

Flexible Printed Circuit Board

Flexible FPC was originally designed as a replacement for traditional wire harnesses. It is often used as connectors replace rigid printed circuit boards where high requirement on flexibility, space savings, or production constraints limit.

Advantage of Flexible Printed Circuit Boards:

  • Flexible PCB design and layout
  • Flexible, space savings
  • Reduced wiring errors
  • Increase tde flexibility of connection compared witd mechanical connectors
  • Easier installation and service
  • Higher circuit density
  • More robust operating temperature range
  • Stronger signal quality
  • Improve manufacturing yield and reliability
  • Improve reliability and impedance control
  • Reduce size and weight
  • Improve aestdetics of finished products

We provide flexible FPC manufacturing service as well as rigid PCB board to meet our customer wide demand. We use advanced manufacturing processes for flexible printed circuits fabrication on polyimide substrates to assure high reliability of products. We specialize in single sided and double sided FPC circuits, also some multi-layer and some flexible FPC assembly, which is widely used in tde customer electronics, medical device, communicating equipment, industrial equipment, and aerospace markets.

Our flexible FPC capacity:

Layers No. 1-6 layers
Finished Board tdickness Min.:10x45mm Max.: 250x1200mm
Available Laminates Material PI,PET,FR4+PI
Finished Board Thickness tolerance ± 0.01mm
Finished hole diameter(Min.) 0.1mm
Finished hole diameter(Max) 0.6mm
NPTH Hole diameter tolerance ± 0.025mm
PTH hole diameter tolerance ± 0.050mm
Copper foil thickness 12um, 18um, 35um, 70um
Circuit width/spacing(Min.) ≥0.065mm (1 / 2oz) ≥ 0.05mm (1 / 3oz)
Surface Finished type OSP, Gold plating, Immersion Gold, Tin plating, Pb/ Pbfree HASL
Gold Flash Ni/Au thickness Ni: In 2.54-9um: 0.025-0.5um
Immersion Tin thickness 0.7-1.2um
Tin plating thickness 3-15
Drill hole position tolerance ± 0.05mm
Punching dimension tolerance ± 0.05mm
Certificate ROHS, UL, ISO9001

Why us?

  • 1. We build your circuit board to the exacting specifications.
  • 2. Our engineer and production staff is with many decades of experience in circuit board.
  • 3. Competitive cost as well as high quality.
  • 4. Excellent service and prompt delivery
  • 5. ISO and UL Certificated and strict control the quality according to IPC standard.
